KAPA RNA HyperPrep Kits
Overview

RNA library preparation is the critical first step of RNA sequencing (RNA-seq) and KAPA RNA HyperPrep kits offers flexible workflow options with streamlined single-tube single-day workflows that include enrichment of desired transcripts by selective mRNA capture or rRNA depletion. These kits have been optimized for high performance even with degraded and low-input samples, and offer the option of custom RNA depletion. KAPA RNA HyperPrep Kits contain high-quality enzymes, including KAPA HiFi DNA polymerase, developed through our Directed Evolution Technology for constructing RNA libraries with minimal GC bias and even sequence coverage.

Download Brochure

Introducing a shorter, more streamlined RNA-seq workflow

This new, optimized workflow for KAPA RNA HyperPrep with RiboErase (HMR) saves over an hour compared to the standard workflow, and as much as 3 hours compared to kits from other suppliers. With this new protocol, the total turnaround time— including ribodepletion— is about 5 hours.

Download the Tech Spotlight to learn more, and contact us for the protocol.



Benefits of KAPA RNA HyperPrep Kits
KAPA RNA HyperPrep Kits Benefits
graph of rRNA vs. mRNA
KAPA RNA HyperPrep Kits compared to 2 suppliers
Depletion of rRNA, user-defined RNA, and globin transcript

Whole-transcriptome sequencing provides a complete view of the transcriptome, including immature and noncoding RNAs. In these workflows, it is important to remove rRNA (up to 95% of the total RNA sample) prior to library prep in order to minimize the number of wasted sequencing reads. This method is effective with degraded RNA inputs not suitable for mRNA capture. Enzymatic depletion can also be used to remove other transcripts, such as globin mRNA and/or other highly abundant RNAs.

mRNA Capture

mRNA capture sequencing is used for the analysis of coding transcripts in eukaryotic samples, allowing researchers to detect and quantify relative expression levels. This workflow enriches for mRNA over non-polyadenylated species such as ribosomal, precursor, and non-coding RNAs.

KAPA RNA HyperPrep Kits provide streamlined, strand-specific library construction.

The novel chemistry employed in KAPA RNA HyperPrep Kits allows for fewer and shorter enzymatic steps, reducing hands-on time and overall library prep time. rRNA depletion with KAPA RiboErase (HMR) or KAPA RiboErase (HMR) Globin Kits adds approximately 2.5 hours to the overall workflow time, whereas mRNA capture adds approximately 1.5 hours. The entire workflow, from input RNA to sequencing-ready library, can easily be completed in a standard workday. All KAPA RNA HyperPrep library construction workflows are automation friendly.

Download Brochure

KAPA RNA HyperPrep Kits Specifications and Comparison

View Full Table

KAPA RNA HyperPrep Kits Specifications and Comparison



Product Name KAPA RNA HyperPrep Kits KAPA mRNA HyperPrep Kits KAPA RNA HyperPrep Kits with RiboErase (HMR) KAPA RNA HyperPrep Kits with RiboErase (HMR) Globin
Library Preparation Duration 4 hours 5.5 hours 6.5 hours 6.5 hours
Sample Input Amount 1-100 ng into library prep 50 ng - 1 µg into mRNA capture 25 ng - 1 µg into rRNA depletion 25 ng - 1 µg into rRNA depletion
Sample Types

High-quality total RNA


Degraded or FFPE total RNA


Poly(A)-selected and/or depleted RNA

High-quality total RNA

High-quality total RNA


Degraded or FFPE total RNA

High-quality total RNA


Degraded or FFPE total RNA


Whole blood total RNA

Species

Eukaryotic (Animal, Plant, etc.)


Prokaryotic (Bacteria, etc.)


Viral

Eukaryotic (Animal, Plant, etc.)

Human, Mouse, and Rat


Other species can be supported via custom rRNA depletion

Human, Mouse, and Rat


Other species can be supported via custom rRNA depletion

Stranded RNA-sequencing Yes Yes Yes Yes
Amplification

KAPA HiFi DNA Polymerase


Compatible with low bias amplification

KAPA HiFi DNA Polymerase


Compatible with low bias amplification

KAPA HiFi DNA Polymerase


Compatible with low bias amplification

KAPA HiFi DNA Polymerase


Compatible with low bias amplification

Reaction Purification KAPA Pure Beads included KAPA Pure Beads included KAPA Pure Beads included KAPA Pure Beads included
Multiplexing Yes.  KAPA Adapters are not supplied, but available separately Yes.  KAPA Adapters are not supplied, but available separately Yes.  KAPA Adapters are not supplied, but available separately Yes.  KAPA Adapters are not supplied, but available separately
Applications

Whole-transcriptome sequencing


Gene expression with target enrichment


Splice junction and gene fusions with target enrichment

Gene expression


Annotation


Splice junction and gene fusions

Whole-transcriptome


Long non-coding RNA Annotation


Gene expression


Splice junction and gene fusions

Whole-transcriptome


Long non-coding RNA Annotation


Gene expression


Splice junction and gene fusions

Automation Friendly Yes.  Demonstrated and verified on
many liquid handling systems.
Learn more
Yes.  Demonstrated and verified on
many liquid handling systems.
Learn more
Yes.  Demonstrated and verified on many
liquid handling systems.
Learn more
Yes.  Demonstrated and verified on many
liquid handling systems.
Learn more
Compatible Sequencing Platforms Illumina Sequencers Illumina Sequencers Illumina Sequencers Illumina Sequencers
Storage Information

Enzymes and buffers can be stored for up to 10 months at -20°C



KAPA Pure Beads can be stored for up to 10 months at 4°C

Enzymes and buffers can be stored for up to 10 months at -20°C



KAPA Pure Beads can be stored for up to 10 months at 4°C

Enzymes and buffers can be stored for up to 10 months at -20°C



KAPA Pure Beads can be stored for up to 10 months at 4°C

Enzymes and buffers can be stored for up to 10 months at -20°C



KAPA Pure Beads can be stored for up to 10 months at 4°C

The first-generation KAPA Stranded RNA-seq Kits are still available for purchase. For more information about these older RNA library kits, please click here.

Ordering

View Full Table

Ordering

KAPA Code
Roche Cat. No
Description
Kit Size
How to buy
KK8560
08098131702

KAPA RNA HyperPrep with RiboErase (HMR)

24 libraries
Login for pricing
KK8561
08098140702

KAPA RNA HyperPrep with RiboErase (HMR)

96 libraries
Login for pricing
KK8540
08098093702
KAPA RNA HyperPrep Kit 24 libraries
Login for pricing
KK8541
08098107702
KAPA RNA HyperPrep Kit 96 libraries
Login for pricing
KK8580
08098115702
KAPA mRNA HyperPrep Kit 24 libraries
Login for pricing
KK8581
08098123702
KAPA mRNA HyperPrep Kit 96 libraries
Login for pricing
KK8562
08308314702

KAPA RNA HyperPrep Kit with RiboErase (HMR) Globin

24 libraries
Login for pricing
KK8563
08308241702

KAPA RNA HyperPrep Kit with RiboErase (HMR) Globin

96 libraries
Login for pricing
KAPA Code
Roche Cat. No
Description
Kit Size
How to buy
KK8721
08278539001
KAPA Adapter Dilution Buffer (25 mL) 25 mL
Login for pricing
KK8727*
08861919702

KAPA Unique Dual-Indexed Adapter Kit, (15 µM)

96 adapters x 20 µl each
Login for pricing
*Contains KAPA Adapter Dilution Buffer, as well as three additional sealing films to support multiple use

KAPA RNA HyperPrep Kits

These fast, robust RNA library preparation kit can be used with a wide variety of RNA input types, qualities, and amounts, and they also enable different workflow options including ribosomal depletion and mRNA capture for eukaryotic or prokaryotic RNA-seq libraries.

KAPA RNA HyperPrep with RiboErase (HMR)
  • Includes all reagents for efficient enzymatic depletion of ribosomal RNA (rRNA) from human, mouse, and rat (HMR) samples of high-or low-quality RNA
  • Provides a more comprehensive view of the whole transcriptome compared to mRNA capture
  • Can be used for custom depletion of rRNA from other organisms when the HMR oligos are replaced with custom sequences

Efficient rRNA depletion using KAPA RNA HyperPrep with RiboErase (HMR) leads to fewer non-informative reads and the detection of more unique transcripts compared to other suppliers.

Libraries were generated in quadruplicate using variable inputs of Universal Human Reference (UHR) RNA (Agilent Technologies) with rRNA de[pletion prior to library construction. Where present, error bars represent the standard deviation. For 25 ng samples, paired end (2 x 100 bp) sequencing was performed using an Illumina® HiSeq® 2500 instrument. Reads aligning to rRNA were removed, and reads were randomly subsampled to 14 M for comparative analyses. Transcripts were quantified using RNA-SeQC. The 10 ng input amount is lower than the validated minimum input for both KAPA RNA HyperPrep workflows; for these samples, paired-end (2 x 75 bp) sequencing was performed using an Illumina NextSeq 500 instrument. Reads were randomly subsampled to 14 M for comparative analysis prior to removing reads aligning to rRNA and subsequent marking of duplicates. Transcripts were quantified using Kallisto (data not plotted due to analysis and sequencing depth differences).

KAPA RNA HyperPrep with RiboErase (HMR) Globin
  • Includes all reagents for efficient enzymatic depletion of globin mRNA from blood-derived RNA samples from high- or low-quality RNA
  • Includes reagents for the depletion of human, mouse, or rat (HMR) rRNA

KAPA RNA HyperPrep Kit with RiboErase (HMR) Globin simultaneously removes rRNA and globin mRNA from blood-derived RNA. Together, effective RNAase H depletion and highly efficient library construction result in fewer non-informative reads

(A) compared to the workflow from Supplier I, which employs bead-based depletion (orange). This translates to more complex libraries (B) and a larger number of unique transcripts detected (C).

Libraries were prepared from different inputs of RNA extracted from human blood, as indicated on the x-axis of each graph. The 25 ng input is lower than the recommended minimum input for the Supplier I workflow. Paired-end (2 x 125 bp) sequencing was performed on an Illumina® HiSeq® 2500 instrument. Data were sub-sampled to 17 M reads per sample for analysis. Each bar represents the average of three technical replicates. Transcript abundance was quantified using Kallisto. To assess off-target depletion, transcript abundances were aggregated at the gene level and TMM-normalized prior to differential expression analysis. The expression profiles of libraries generated with or without globin depletion were compared to assess off-target depletion for each workflow.

KAPA mRNA HyperPrep Kit
  • Includes reagents for the enrichment of eukaryotic mRNA from high-quality total RNA
  • Provides a focused view of the protein-coding regions of the transcriptome

Efficient mRNA capture using KAPA mRNA HyperPrep leads to fewer non-informative reads and the detection of more unique transcripts compared to other suppliers.

Libraries were generated in quadruplicate using variable inputs of Universal Human Reference (UHR) RNA (Agilent Technologies) with mRNA capture prior to library construction. For 50 ng samples, paired end (2 x 100 bp) sequencing was performed using an Illumina® HiSeq® 2500 instrument. Reads aligning to rRNA were removed, and reads were randomly subsampled to 14 M for comparative analyses. Transcripts were quantified using RNA-SeQC. The 10 ng input amount is lower than the validated minimum input for both KAPA RNA HyperPrep workflows; for these samples, paired-end (2 x 75 bp) sequencing was performed using an Illumina NextSeq 500 instrument. Reads were randomly subsampled to 14 M for comparative analysis prior to removing reads aligning to rRNA and subsequent marking of duplicates. Transcripts were quantified using Kallisto (data not plotted due to analysis and sequencing depth differences).

Single-cell full-length total RNA sequencing uncovers dynamics of recursive splicing and enhancer RNAs

Hayashi et al. describe the first method for full-length total RNA-sequencing for single cells, which they developed using KAPA HiFi DNA Polymerase, KAPA RNA HyperPrep Kit with RiboErase (HMR), and KAPA Library Quantification Kit. This method — random displacement amplification sequencing (RamDA-seq) — enables the investigation of gene expression dynamics, RNA-processing, and transcriptional regulation in single cells.

Read Manuscript

Comparing library preparation methods for SARS-CoV-2 multiplex amplicon sequencing on the Illumina MiSeq platform

Batty, E.M. et al.

bioRxiv 20202020
In the article, Batty, E.M. et al. present their findings from a comparison of three different library preparation methods used in the ARTIC Network protocol for SARS CoV- 2 multiplex amplicon sequencing on the Illumina® MiSeq® platform. The authors report that the ligation-based KAPA HyperPrep method resulted in higher library yield, more total reads, and equal or better overall coverage than the tagmentation-based Nextera Flex or Nextera XT workflows.

Read Manuscript

Blocking of the CD80/86 axis as a therapeutic approach to prevent progression to more severe forms of COVID-19

Julia et al.

aRxiV.org2020

Julia et al. used KAPA RNA HyperPrep with RiboErase (HMR) Globin to investigate the transcriptional responses of SARS-CoV-2-infected patient samples to the immunomodulating drug Abatacept, and to compare this response to that of cells and blood from Rheumatoid Arthritis patients. The authors used this data to determine whether blocking the CD80/86 axis is a viable therapeutic target to prevent severe immune responses of COVID19 patients.

Read Manuscript

Hydroxychloroquine inhibits trained immunity – implications for COVID-19

Rother et al.

medRxiV.org2020

Rother, N. et al. constructed total RNA-seq libraries using KAPA RNA HyperPrep Kit with RiboErase (HMR) to perform transcriptome analysis of isolated monocytes of COVID-19 patients. These cells demonstrated increased expression of interferon-stimulated genes, which are likely markers of disease severity as they are associated with a poor clinical outcome. Using the Kapa HyperPrep Kit, the authors also constructed ChIP-seq libraries to investigate the effect of hydroxychloroquine on trained immunity at the functional and epigenetic level.

Read Manuscript


COVID-19 Related Genes in Sputum Cells in Asthma: Relationship to Demographic Features and Corticosteroids.

Peters M. C. et al.

PubMed2020

Peters et al. used the KAPA mRNA Hyper Prep Kit in Whole Transcriptome RNA-seq to investigate host expression levels of angiotensin-converting enzyme 2 (ACE2) and transmembrane protease serine 2 (TMPRSS2), two proteins believed to mediate SARS –CoV2 viral infection of host cells.

SARS-CoV-22020RNA-Seq

Read Manuscript


Clinical benefit of remdesivir in rhesus macaques infected with SARS-CoV-2

Williamson et al.

bioRxiV.org2020

Williamson et al. use the KAPA HyperPlus Library Preparation Kit and KAPA Unique Dual-Indexed Adapters to prepare sequencing libraries from double-stranded cDNAs converted from SARS-CoV-2 viral RNA. Williamson et al. also amplified the resulting libraries using KAPA HiFi HotStart ReadyMix and quantified them with the KAPA Library Quantification Kit prior to paired-end sequencing.

LQK2020SARS-CoV-2DNA-Seq

Read Manuscript



A Territory-wide study of COVID-19 cases and clusters with unknown source in Hong Kong community: A clinical, epidemiological and phylogenomic investigation.

Leung K. S. et al.

medRxiV.org2020

Leung et al. prepared sequencing-ready libraries with the KAPA HyperPrep DNA Library Prep Kit following generation of amplicons by multiplex PCR using ARCTIC network nCoV-2019 primers; through that workflow, Leung et al. investigated the epidemiological and phylogenomic characteristics of COVID-19 cases in Hong Kong.

SARS-CoV-22020DNA-Seq

Read Manuscript



Patient-derived mutations impact pathogenicity of SARS-CoV-2

Yao H. et al.

medRxiV.org2020

Yao et al. performed whole viral genome sequencing using KAPA RNA-Seq library prep kit from COVID-19 patient isolates to understand whether acquired mutations of the SARS-CoV-2 genome have an impact on the pathogenicity of the virus.

SARS-CoV-22020RNA-Seq

Read Manuscript



Transcriptional profiling of immune and inflammatory responses in the context of SARS-CoV-2 fungal superinfection in a human airway epithelial model

de Lamballerie, C.N. et al.

bioRxiV.org2020

Following construction of poly(A)-enriched RNA-seq libraries with the KAPA mRNA HyperPrep Kit, de Lamballerie et al. compared the host transcriptional response to SARS-CoV-2 infection alone to that of SARS-CoV-2 with Aspergillus superinfection to elucidate the impact of fungal superinfections on the course and severity of viral infections in respiratory epithelial cells.

2020RNA-SeqSARS-CoV-2KAPA mRNA HyperPrep Kits

Read Manuscript



Expression of SARS-CoV-2 Entry Molecules ACE2 and TMPRSS2 in the Gut of Patients with IBD
Burgueno et al.

Inflammatory Bowel Disease2020

Burgueno et al. used the KAPA RNA HyperPrep Kit with RiboErase (HMR) and the LightCycler® 480 System to understand the expression of the viral entry molecules angiotensin I converting enzyme 2 (ACE2) and transmembrane serine protease 2 (TMPRSS2) in the intestine. Additionally, the authors investigated how inflammatory states in the gut of patients suffering from inflammatory bowel disease (IBD) and taking immune-modu

2020RNA-SeqSARS-CoV-2LightCycler 480KAPA RNA HyperPrep Kits with RiboErase

Read Manuscript



The circulating SARS-CoV-2 spike variant N439K maintains fitness while evading antibody-mediated immunity

Thomson, E.C. et al.

bioRxiv 20202020

Immune evasion mutations that maintain virulence and fitness can emerge within the SARS-CoV-2 spike protein, highlighting the need for ongoing molecular surveillance to guide development and usage of vaccines and therapeutics. Thomson, E.C. et al. used the ARTIC network amplicon sequencing protocol and the https://doi.org/10.1101/2020.11.04.355842 to conduct epidemiological and genome surveillance of SARS-CoV-2 and

SARS-CoV-22020DNA Library Preparation

Read Manuscript
